Pillow A4 Paper Horizontal Packaging Machine

FOB Reference Price:Get Latest Price
US $2,000-6,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Multi-Function Packaging Machine
Condition:
New
Function:
Filling, Labeling, Sealing
Application:
Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical
Packaging Type:
Bags, Film, Foil, Pouch
Packaging Material:
Paper, Plastic
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220v/380v/customized
Power:
2.4kw
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
Huihe pack
Model Number:
HP-250
Dimension(L*W*H):
L3770*W670*H1450mm
Certification:
CE ISO
After-sales Service Provided:
Engineers available to service machinery overseas
Product name:
Pillow A4 Paper Horizontal Packaging Machine
material:
according to requirement carbon steel,stainless steel 304,316L
bag type:
pillow bag
manual:
English version
Packing speed:
50-100bags/min
after-sales service:
full life
guarantee:
1 year
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
exporting standard wooden case
Port
shanghai port
Lead Time :
after deposit 25 working days
Video Description
Contact Details

WhatsApp---008613917995074

Skype---sweetcandy66584

Wechat---1587694896

HP-250/320/350 High Speed Auto Pillow Packing Machine

Pillow A4 Paper Horizontal Packaging Machine

Pillow Type Packaging machine biscuit energy bar packaging machine Automatic

Feature

1. Double motor, double Panasonic transducer control and PLC controller,flexible bag length cutting, operator neednt to adjust the unloading working, saving time and saving films.
2, Buttoned human-machine screen, Chinese or English displaying, convenient and quick parameter setting.
3. Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking, digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. .All the controls are achieved by software, convenient for function adjusting and upgrading.



Specification

Model No.HP-250 HP-320HP-350
Film widthMax.250mmMax.320mm Max.350mm
Bag length65-190 or 120-280mm 65-190 or 120-280mm65-190 or 120-280mm
Bag width30-110mm 50-150mm50-160mm
Product heightMax.55mm Max.55mmMax.55mm
Film roll diameterMax.320mmMax.320mmMax.320mm
Packing speed40-230bag/min 40-230bag/min40-230bag/min
Power supply220V 50/60Hz 2.4kw 220V 50/60Hz 2.6kw 220V 50/60Hz  2.8kw
Machine size3770*670*1450mm 4020*720*1320mm4020*770*1450mm
Machine weight800kg900kg900kg



Application

Suit for food, medicine, daily necessities,disposable product, hardware product, plastic

product,toy, industrial goods, industrial parts and car accessories industries.





Packing samples










Specification

Model No.HP-250 HP-320HP-350
Film widthMax.250mmMax.320mm Max.350mm
Bag length65-190 or 120-280mm 65-190 or 120-280mm65-190 or 120-280mm
Bag width30-110mm 50-150mm50-160mm
Product heightMax.55mm Max.55mmMax.55mm
Film roll diameterMax.320mmMax.320mmMax.320mm
Packing speed40-230bag/min 40-230bag/min40-230bag/min
Power supply220V 50/60Hz 2.4kw 220V 50/60Hz 2.6kw 220V 50/60Hz  2.8kw
Machine size3770*670*1450mm 4020*720*1320mm4020*770*1450mm
Machine weight800kg900kg900kg



Application

Suit for food, medicine, daily necessities,disposable product, hardware product, plastic

product,toy, industrial goods, industrial parts and car accessories industries.





Packing samples









After Sales Service:

1.Guaranty: One Year.



2.One set of consumable accessories will be provided with the machine.



3.Any question, you can mail/call us at any time. And our most experienced engineers are assigned to give consulting service, and always available for dispatching abroad.



4.All spare parts are always available for delivery.



5.Manual is in English.



Installation/ Training

If really dont know how to install and operate after showing the video and telephone instruction, you can ask for installation from us. It must be after shipment till the machine has arrived and factory must be ready equipped with all necessary requirements before booking installation. Our engineers will come to the site for the complete and final installation. During the installation session, a one-day training course will be provided to our customers about operation and maintenance procedure. The following costs should be paid by the buyer, including engineer's all local transportation, accommodation, and air tickets (round trip).



Payment terms

Choose the machine type →  Goods delivery :(FOB,CIF,CFR,EXW)  →  Payment term :30% down payment as for ordering the machine (or 100 % payment that can save time )  →  Confirmed the machine requirement  →   Based on your requested to producing machine→   Though video chat or send machine picture or directly come to inspection in our factory →  Pay the rest of balance 70% → Arrange the  shipment .(If need more technical support ,please contact our services )
